Powerful static eliminator prevents jamming, tearing, shocks and dust up to 20′ away!
What Is The Super Ion Air Knife?
EXAIR’s Gen4 Super Ion Air Knife off ers 34% improved performance at low pressures allowing you to achieve the same or better results, which saves compressed air and money. Gen4 Super Ion Air Knives remove static electricity from plastics, webs, sheet stock and other product surfaces where tearing, jamming or hazardous shocks are a problem. The laminar sheet of air sweeps surfaces clean of static, particulate, dust and dirt. Production speeds, product quality, and surface cleanliness can improve dramatically.
Super Ion Air Knife Specifications
The Gen4 Super Ion Air Knife is available in standard lengths of 3″, 6″, 9″, 12″, 18″, 24″, 30″, 36″, 42″, 48″, 54″, 60″, 72″, 84″, 96″ and 108″ (76, 152, 229, 305, 457, 610, 762, 914, 1067, 1219, 1372, 1524, 1829, 2134, 2438 and 2743mm). Special lengths and unlimited system lengths are available .
A 5′ (1.52m) armored and electromagnetically shielded power cable with ground and assembled bayonet connector are included.
EXAIR Model 7960 or 7961 Gen4 Power Supply (5kV) is required for bar operation. Power supplies are equipped with a modular 6′ (1.83m) power cord, lighted power switch integrated fuse on the primary and (2) or (4) high voltage outlets.
Certifications: Gen4 Ionizing Bars and Gen4 Power Supplies are UL Component Recognized to U.S. and Canadian safety standards, and are CE and RoHS compliant.
Compressed Air: 1/4 NPT inlets are provided on each end and the bottom.
Electrical: For use with Model 7960 or 7961 5 kVrms, 5 milliamperes (max.) power supply.
Electrical Hazard: Gen4 Ionizing Bars are shockless (less than 40 microamperes short circuited).
Do not use near flammable materials or gases.
- Materials of Construction: Metal Parts: Aluminum
- Plastic Parts: UL rated 94 HB
- Emitters: Stainless Steel
Maximum Ambient Temperature: 165°F (74°C)
Warrantee: 5 years
